MA5626 GPON EPON ONU 4 ports MDU
Short Description:
| Type | Function |
| Emulation service | l Point-to-Point Protocol over Ethernet (PPPoE) dialup service emulation l Dynamic Host Configuration Protocol (DHCP) dialup service emulation l Multicast emulation |
| Layer 3 features | l IPv6 l VLAN Layer 3 interface l Address Resolution Protocol (ARP) l Domain name server (DNS) client l Static route |
| Networking features | l Multiple Spanning Tree Protocol (MSTP) l Link Aggregation Control Protocol (LACP) l PON type B protection (supported when the MA562MA5626 works with the optical line terminal (OLT)V800R009 or later versions) l Ring detection |
| User security | l Policy Information Transfer Protocol (PITP) l DHCP option82lAuthentication, Authorization,and Accounting(AAA) l 802.1xauthenticationlRelay agent info option (RAIO) l Anti-MAC address transfer l Anti-MAC address spoofing l Anti-IP address spoofing l User isolation |
| System security | l Source IP address filtering (IP address access list) l Source MAC address filtering l Destination MAC address filtering l Anti-denial of service (DoS) attacks l Anti-IP address attacks l Anti-Internet Control Message Protocol (ICMP) packets attacks l Source route filtering l Firewall l Blacklist |
| Operation and maintenance security | l 1User account and password management l Simple Network Management Protocol v3 (SNMPv3based authentication, encryption, and access control l Setting of independent security administrator l Encryption for file transfer l Encryption for remote management and connection l Security event logging |
| Line security | l Advanced Encryption Standard (AES) 128 encryption GPON downstream transmission |
| Operation and maintenance features | l Local operation and maintenance l Remote operation and user management l 1Version and data management l Device exception management Environment monitoring l One environment monitoring |
| environment monitoring | l One environment monitoring port that can monitor four digital parameters l Default digital parameters: smoke, door status, surge protection, and main distribution frame |
