Huawei Vector Mini IP dslam MA5818
Short Description:
| Dimensions | 482.6mm×245mm×88.1mm |
| Network-side port | ADSL2+,VDSL2,SHDSL,POTS,ISDN,FE/GE |
| User-side port | The MA5616 provides four slots and the following 10 service boards: • 24-channel VDSL2 board (17a, over POTS, built-in SPL) • 24-channel VDSL2 board (17a, over POTS, external SPL) •24-channel VDSL2 board (17a, over ISDN, external SPL) •16-channel VDSL2 board (30a, over POTS, built-in SPL) • 32-channel ADSL2+ board (built-in SPL) • 32-channel combo board (32 × POTS + 32 × ADSL2+) • 64-channel POTS board •32-channel POTS board • 8-channel ISDN board •16-channel G.SHDSL board (supporting ATM and PTM) |
| Operating temperature | -40oC to 65oC; startup at -25oC |
| Humidity | 5% to 95% (non-condensing) |
| Heat dissipation mode | Providing fans for heat dissipation. The rotating speed can be automatically adjusted. |
| Lightning protection capability | GE/FE: 6 kVPOTS: 4 kV |
| Backup power | Support for 48-V backup power Support for lead-acid batteries and LiFePO4 batteries |
| Weight | 4.8 kg (empty chassis) 7.2 kg (full configuration) |
