Combasst OEM CBT1003 VDSL2 Modem internet wifi modem
Short Description:
| Model | CCPAM1000 |
| Ports | 10/100Base-TX: 4 RJ-45, Auto-negotiation and Auto-MDI / MDI-X VDSL: 1 RJ-11, female Phone Jack PHONE: 1 RJ-11, Built-in splitters for POTS / ISDN connection |
| DIP Switch | 4 position DIP switch |
| Functionality | • CO / CPE mode select • Selectable fast and interleaved mode • Selectable target data rate • Selectable target SNR mode |
| Encoding | • VDSL-DMT - ITU-T G.993.1 VDSL - ITU-T G.997.1 - ITU-T G.993.2 VDSL2 (Profile 12a Support), Annex A |
| LED Indicators | • One Power • 3 for RJ-11 / VDSL2 WAN : - Green, LNK / ACT - Green, CO mode - Green, Rate • 2 for per RJ-45 10/100Base-TX port - Green, LNK / ACT - Green, Speed |
| Cabling Type | • 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft) • 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft) • VDSL: twisted-pair telephone or ISDN wires (AWG24 or better) up to 1.2km |
| Performance | • Full VDSL2 bandwidth up to: (Down Stream / Up Stream) - 200m -> 100/55Mbps - 400m -> 90/40Mbps - 600m -> 70/10Mbps - 800m -> 48/8Mbps - 1000m -> 30/6Mbps |
| Dimension (W x D x H) | 120 x 173 x 38 mm |
| Weight | 0.3 kg |
| Power Requirement | 12V DC1A |
| Operating Temperature | 0~50 Degree C |
| Storage Temperature | -25~70 Degree C |
| Operating Humidity | 10~90%, relative humidity, non-condensing |
| Storage Humidity | 10~90%, relative humidity, non-condensing |
| Regulation Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX ITU-T - G.993.1 (VDSL) - G.997.1 - G.993.2 VDSL2 (Profile 12a ), Annex A |
