huaweie 48-port GE/FE Optical Interface Board H802OPGE for MA5608T OLT
Short Description:
| Specification | H802OPGE |
| Port Quantity | 24/48 |
| Optical Module | CSFP (48-channel) or SFP (24-channel) GE/FE |
| Limit on the Traffic Classification Parameters | The user VLAN ID ranges from 1 to 4093, but cannot be set to 4094 or 4095.The user VLAN packets cannot be priority-tagged. |
| Cascading and aggregation of DSLAMs or MDUs | YesNOTE:You can run the network-rolecommand in the opg mode to switch the board role. Default board role is user. |
| Synchronous Ethernet clock issuing | Yes |
| 1588v2 clock issuing | Yes |
| Inter-board aggregation and load sharing | Yes |
