IPTV Headend 4K HDMI 1080P 60fps Encoder
Short Description:
| Model | HDMI 4K60 encoder |
| Input | One HDMI |
| Output | IP signal,1 HDMI,1 audio output |
| Video | |
| Input resolution | 4096*2160/3840*2160/2048*1152/1920x1080p/1280x720p |
| Coding level | H.265/H.264 H.265 MP LEVEL 5.0 H.264 HP/MP/BP LEVEL 5.1 |
| Encoded size | 640*360~4096*2160(Can customize) |
| Video bit rate | Rate control: CBR/VBR 16KBIT/S~200MBIT/S |
| Video frame rate | 30/60fps |
| OSD | Character, images |
| Audio | |
| Input selection | 1channel embedded audio hdmi, Support audio gain |
| Audio coding | AAC/G.711 |
| Audio bit rate | 24Kb/s~256Kb/s |
| Sampling rate | 44100/48000 |
| IP Output | 1 RJ45 1000M adaptive Ethernet port, TS stream standard, ONVIF protocol |
| System | |
| Network protocol | Support HTTP,RTSP,RTMP,UDP,RTP.multicast, unicast |
| Configuration management | Support IE configuration, remote upgrade |
| Generally | |
| Power supply | 12V~2A |
| power consumption | 5W |
| Size | 100mm x110mm x 40mm(length*width*height) |
| Operating temperature | -20℃+ 60℃ |
| Working humidity | <90%,Non-condensing |
| Weight | 0.3KG |
