HDMI RTP IPTV MPEG4 H.264 UDP Fujitsu Chipset Encoder
Short Description:
| SNK6092A/SNK6096A (HDMI) | SNK6320L |
| Chipset | |
| Fujitsu | Hisilicon |
| Video Channel | |
| 4/8×HDMI optional | 4/8/12/16/20/24×HDMI optional |
| Video Bit Rate | |
| 0.8Mbps~19Mbps each channel(Bit rate is with a low fluctuation, suitable for cable system and satellite uplink) | 1Mbps~13Mbps each channel(Bit rate is with a high fluctuation, suitable for cable system, not suitable for satellite uplink) |
| GOP | |
| IBBP | GOP Size=25 (without B Frame) |
| Resolution | |
| Up to 1080p-60 | Up to 1080P-30(1080i/p-60/50 to 1080p-30/25 auto downscale convertion) |
| Audio Encode | |
| MPEG-1 Layer II;HE-AAC V2, LC- AAC Optional;AC3 passthrough | MPEG-1 Layer II |
| Audio Gain | |
| 0-400 Adjustable | 0-255 Adjustable |
| ASI In & Mux | |
| Yes | N/A |
| ASI output | |
| Yes | Option as required |
| IP output | |
| SPTS and 1MPTS | SPTS and 1MPTS (for 4/8/12 channel)SPTS or 1MPTS (for 16/20/24 channel) |
