| Items |
|
| Unit |
Performance Index |
| Optical Operating Wavelength |
|
| nm |
1535～1565 |
| Input Optical Power Range |
|
| dBm |
-10～+10 |
| Noise Ratio |
|
| dB |
≤5.0 (0 dBm,@1550nM) |
| Gain Flatness |
|
| dB |
＜±0.3 |
| Optical Power Output Stability |
|
| dB |
＜±0.5 |
| Polarization Sensitivity |
|
| dB |
＜0.2 |
| Polarization Mode Dispersion |
|
| Ps |
＜0.5 |
| Input End Pump Leakage Power |
|
| dB |
≤-30 |
| Output End Pump Leakage Power |
|
| dB |
≤-30 |
| Optical Input, Output Return Loss |
|
| dB |
＞45（APC Stepped Face） |
| Pump Operating Number |
|
| PCs |
2～5 |
| Rated Output Power |
|
| dBm |
27～45 |
| Linker(IN) |
|
| - |
SC/APC |
| Linker(OUT) |
|
| - |
LC/APC |
| Power Supply/Consumption |
|
| V/W |
DC-48/20 |
| Operating/Storage Temperature |
|
| ℃ |
-20～65/-30～70 |
| Operating/Storage Humidity |
|
| % |
5～90 |
| Case Size |
|
| mm |
530×486×88 (2U) |
| Network Management Connector |
|
| / |
RJ45(following national network management standard, supports WEB) |
|
| XG(S)- PON Wavelength |
| nm |
1310/1490 & 1270/1577 |
|
| XG(S)- PON Linker |
| / |
LC/UPC |
|
| Uplink optical ports |
| pcs |
32 |
|
| Output ports |
| Pcs |
32 |
|
| XG(S)- PON Insertion Loss |
| dB |
＜1.2 |
|
| 1550 Port Insertion Loss |
| dB |
＜0.7 |
|
| Optical isolation between CATV&OLT |
| dB |
40 |
| Optical Switch |
| Insertion Loss |
| dB |
＜1 |
|
| Harass |
| dB |
＜-60 (isolation between A and B) |
|
| Switch Time |
| ms |
＜10 |
|
| Switched Power Threshold Range |
| dBm |
-5～10 |
