HW ANTDG0404D4SR ANTDG0304A1SR TQJ-2400-11-T2 WLAN Antennas

Product Detail

Antenna Model
Beamwidth

Dimensions
Connector
VSWR	Weight (Without the Mounting Bracket) (kg)

Horizontal (℃)
Vertical (℃)
Diameter x Length/H x W x D


ANTDG0404D4SR
360
110
20 mm x 150 mm x 150 mm
1 x RP-SMA-J
2	0.45
ANTDG0304A1SR*
360
110
桅14 mm x 149 mm
1 x RP-SMA-J
2	0.012
TQJ-2400-11-T2
360
9
Length < 1100 mm
1 x N-female
1.5	0.976
ADU451100
60
30
60 mm x 250 mm x 155 mm
2 x N-female
1.5	1
ASB115G00
60
30
55 mm x 230 mm x 145 mm
2 x N-female
2	1.3
ASB185G00
15
15
25 mm x 250 mm x 250 mm
2 x N-female
2	1.3
AD24145D00
30
30
25 mm x 250 mm x 250 mm
2 x N-female
1.5	0.6
AD515145D00
32
32
25 mm x 220 mm x 120 mm
2 x N-female
2	0.8
ANTDG1211D4NR
35
35
35 mm x 450 mm x 420 mm
4 x N-female
2	3.2

26
26



ANTDG1317D4NR
32
32
35 mm x 450 mm x 420 mm
4 x N-female
2	3.2

15
15



ANTDG1316D4NR
33
33
33 mm x 380 mm x 380 mm
4 x N-female
2	2.18

18
18



ANTDG1313D4NR
33
33
33 mm x 380 mm x 380 mm
4 x N-female
2	2.15

30
30



ANT2G18D2NS
18
18
33 mm x 380 mm x 380 mm
2 x N-female
2	2.2
ANTDG0808D4NR*
70
70
40 mm x 220 mm x 220 mm
4 x N-female
2	0.75
SL12432A
60
7
100 mm x 1125 mm x 350 mm
4 x N-female
2	11
ANT5G15D2NR
45
15
60 mm x 240 mm x 133 mm
2 x N-female
2	0.6
ANT5G15D2NW
45
15
60 mm x 240 mm x 133 mm
2 x N-female
2	0.8
ANT5G16D4NW
25
25
64 mm x 265 mm x 134 mm
4 x N-female
2	1.26
ANT5G16D4NP
25
25
64 mm x 265 mm x 134 mm
4 x N-female
2	1.26
ANTDG0407A1NR
360
25
桅23.8 mm x 275 mm
1 x N-J
2	0.106

360
15



ANTDG0407A1NS
360
30
桅23.8 mm x 235 mm
N-Male脳1
2	0.09

360
15



ANTDG1115D4NM
30
30
45 mm x 450 mm x 240 mm
4 x N-male
2	2.7

15
15
