| Main features |
Systems Architecture |
| Power consumption |
349W with all 64 ports operating at 64G (48 ports populated with 64G SWL transceivers and 8 ports populated with 2x64G SFP-DD SWL transceivers).
57W for an empty chassis with no transceivers.
|
| Scalability |
Full-fabric architecture with a maximum of 239 switches
|
| Certified maximum |
4K active nodes; 56 switches, 19 hops in Brocade Fabric OS fabrics.
|
| Management access |
10/100/1000Mb/s Ethernet (RJ-45) port and serial console port (mini-USB).
|
| ISL Trunking |
Frame-based trunking with up to eight SFP+ ports per ISL trunk; up to 512Gb/s per ISL trunk. Exchange based load balancing across ISLs with Dynamic Path Selection (DPS) included in Brocade Fabric OS. |
| USB |
One standard USB port for firmware download, SupportSave, and configuration upload or download. |
| Vibration |
Operating: 0.25 Grms sine, 0.40 Grms random, 5 Hz to 500 Hz
Nonoperating: 5 Hz at 0.50 Grms; 10–500 Hz at 1.00 Grms (sine vibration); 3–500 Hz at 1.12 Grms (random vibration)
|
| Power supply |
Dual, hot-swappable redundant power supplies with integrated system cooling fans.
80 Plus Gold.
|
