| Function and Parameters |
| ZXONE 8200 |
| ZXONE8300 |
ZXONE8500 |
| Power Supply |
| -48DC(-60V~40V) |
| |
|
| Maximum Power Consumption |
| 1704W(40x10G) |
| 3318W(80x10G) |
4830(160x10G) |
| Dimensions(H*W*D) |
| 447 mm x 535 mm x 275 mm |
| 897 mm x 535 mm x 275 mm |
1425 mm x 535 mm x 275 mm |
| Weight |
| 15kg |
| 26kg |
37kg |
| Trans Dimensions(H*W*D) |
422 mm x 533mm x 286 mm |
| Trans Weight |
12.5kg |
| Fixed Interface |
| 23 |
| 46 |
69 |
| Admission |
STM-N,POS,ATM,GE ,10GE,FC,ESCON,FICON,DVB |
| transmittability |
10G-5000KMZ(300KM),40G-2000KM |
| intersect |
WSS.-2~10 ROADM,ODUO/1/1/3,800G/1.6T/3.2T |
| Working Temperature |
Long term working temperature: 0 ℃ ~+45 ℃ |
| Humidity |
Long term working Humidity10%~90% |
| MTBF/MTTR |
>235002 hours/ < 30 minutes |
