Epon olt 2 port supply most brand onu mini 2pon ftth olt fiber optic equipment without pon modules

Short Description:


Product Detail

Technical Specification
Parameter Specifications
Operating wavelength 1310(RX)/1490(TX)
Optical power +0 ~ +7dBm
Receiving sensitivity -27dBm
Max distance 20km
Max splitter ratio 1:64
Capacity 2 PON, standard: 64   maximum:128 ONUs   (optional 1:128)
MAC 8K
Uplink port 2  1000M Ethernet RJ45 ports
PON port 2 SFP PON PORTS 1.25G
Control port RJ45 console port, to debug the device
MTBF 100,000 hours
EPON traits Support IEEE802.3ah
Support DBA with minimum1Kbps granularity adjustable
Support 1Gbps up link and down link symmetrical bandwidth
Support AES-128 encryption to each Logical Link Identifier
Support powerful OAM function, implement telnet management, maintenance and upgrade
Support auto discovery and auto register of ONU (real-time operation)
Protocols supported Support IEEE802.3, IEEE802.3u, IEEE802.3ab
Support IEEE802.1Q VLAN
Support IEEE 802.1P QoS
Management Support 1GMPv1/v2 protocol report, query and leave message mouse
Support ONU remote configure and upgrade
Support real-time alarm detection, accurate fault location
Support the alarm information sent to the mailbox, support SMS alarm
Working Environment
Power supply AC220V
Power consumption 11W
Operating temperature -10~55℃
Storage temperature -40~70℃
Humidity 5%~90% non-condensing
Dimension 276mm(length) ×200mm(width) ×44mm(height)

xxxxxxx.
