Combasst OEM 100M modem CBT1000 VDSL2 Ethernet Extender
Short Description:
| Model | CBT1000 |
| Ports | 10/100Base-TX: 4 RJ-45, Auto-negotiation and Auto-MDI / MDI-XVDSL: 1 RJ-11, female Phone JackPHONE: 1 RJ-11, Built-in splitters for POTS / ISDN connection |
| DIP Switch | 4 position DIP switch |
| Functionality | • CO / CPE mode select• Selectable fast and interleaved mode• Selectable target data rate• Selectable target SNR mode |
| Encoding | • VDSL-DMT - ITU-T G.993.1 VDSL - ITU-T G.997.1 - ITU-T G.993.2 VDSL2 (Profile 8a,12a, 17a ,30a Support), Annex A Annex B |
| LED Indicators | • One Power• 3 for RJ-11 / VDSL2 WAN : - Green, LNK / ACT - Green, CO mode - Green, Rate• 4 for per RJ-45 10/100Base-TX port - Green, LNK / ACT - Green, Speed |
| Cabling Type | • 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)• 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)• VDSL: twisted-pair telephone or ISDN wires (AWG24 or better) up to 2.4km |
| Performance | • Full VDSL2 bandwidth up to: (Down Stream / Up Stream) 200m -> 100/100Mbps -1000m -> 35/6Mbps 300m -> 100/100Mbps - 1550m -> 24/4Mbps 600m -> 77/50Mbps - 1800m -> 15/0.8Mbps 900m -> 50/20Mbps 2400m -> 2/0.8Mbps |
| Dimension (W x D x H) | 120 x 173 x 38 mm |
| Weight | 0.3 kg |
| Power Requirement | 12V DC1A |
| Operating Temperature | -10~60 Degree C |
| Storage Temperature | -25~70 Degree C |
| Operating Humidity | 10~90%, relative humidity, non-condensing |
| Storage Humidity | 10~90%, relative humidity, non-condensing |
| Regulation Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10Base-TIEEE 802.3u 100Base-TXITU-T - G.993.1 (VDSL) - G.997.1 - G.993.2 VDSL2 (Profile 8a,12a, 17a ,30a Support), Annex A Annex B |
