Huawei gateway gpon MA5631 EOC catv master CMTS
Short Description:
| Port | Gigabit passive optical network (GPON) upstream transmissionGigabit Ethernet (GE) upstream transmissionEthernet over coaxial cable (EoC) service access |
| Layer 2 management | MAC address managementVirtual local area network (VLAN) attribute managementLayer 2 forwarding policy (VLAN+MAC address) |
| Quality of service (QoS) | Priority processingTraffic managementCongestion managementEarly dropTraffic policingService labelingQueue schedulingTraffic shapingAccess control list (ACL) policies |
| Emulation service | Point-to-Point Protocol over Ethernet (PPPoE) emulation |
| Layer 3 features | Dynamic Host Configuration Protocol (DHCP) clientVLAN Layer 3 interfaceAddress Resolution Protocol (ARP)Domain name server (DNS) clientStatic route |
| Networking features | Multiple Spanning Tree Protocol (MSTP)Link Aggregation Control Protocol (LACP)Network Time Protocol (NTP)Ring check |
| Subscriber security | DHCP option 82Relay agent info option (RAIO)Static and dynamic MAC address bindingAnti-MAC spoofingSubscriber isolationEoC PPPoE+ and DHCP option 82 authentication |
| System security | Destination IP address filtering (IP address access list)Source MAC address filteringDestination MAC address filteringAnti-DoS (denial of service) attackFirewallBlacklistSetting of permitted or denied source IP address segmentsVLAN-based anti-IP spoofing and anti-MAC spoofingPPPoE-based aging detection for anti-MAC spoofing subscribers |
| Operation and maintenance security | User account and password managementSimple Network Management Protocol v3 (SNMPv3)-based authentication, encryption, and access controlSetting of independent security administratorsEncryption for file transferEncryption for remote management and connectionSecurity events logging |
| Line security | AES 128 encryption for GPON downstream transmission |
| Operation and maintenance features | Optimized startup timeLocal operation and maintenanceRemote operation and user managementVersion and data managementDevice exception managementGPON MxU authentication |
| Environment monitoring | One Boolean-value environment monitoring port that can supplies four digital parameters (digital parameters can be flexibly configured and the default digital parameters are smoke, door status, lightning protection, and main distribution frame.) |
| Power supply management | 60 V AC remote power supply and 220 V AC local power supply300 V AC long-term overvoltage resistance and automatic recovery of the power supply voltagePower voltage detection |
