| Technical Specification |
|
| Parameter |
Specification |
| Switching Capacity |
140Gbps |
| Forwarding Capacity(Ipv4/Ipv6) |
104MPPS |
| Service Port |
8*PON port4*GE COMBO port, 2*10GE SFP+ port |
| Redundancy Design |
Single power supply or dual power supplySupport AC input, or DC input |
| Power Supply |
AC: input 90～264V 47/63Hz;DC: input -36V～-72V; |
| Power Consumption |
≤110W |
| Dimensions |
440mm×44mm×380mm |
| Environmental Requirements |
Working temperature: -10°C～55°CStorage temperature: -40°C～70°CRelative humidity: 10%～90%, non-condensing |
