Input
|
8×HDMI (or SDI) inputs
|
|
Video
|
|
Resolution
|
1920×1080_60P, 1920×1080_50P
|
|
Encoding
|
MPEG-4 AVC/H.264
|
|
Bit-rate
|
0.8Mbps~19Mbps (each channel)
|
|
Rate Control
|
CBR/VBR
|
|
GOP Structure
|
IBBP
|
|
Advanced Pretreatment
|
De-interlacing, Noise Reduction, Sharpening
|
|
Low delay
|
50-500 ms available
|
|
Audio
|
|
Encoding
|
MPEG-1 Layer 2 (HE-AAC V2, LC- AAC Option);
AC3 passthrough (for HDMI)
|
|
Sampling rate
|
48KHz
|
|
24-bit
|
Resolution
|
|
Bit-rate
|
64Kbps~384Kbps each channel
|
|
Audio Gain
|
0-400
|
|
Multiplexing
|
1 ASI input multiplexed with local 8 channels of TS
|
|
Stream output
|
2*ASI output, BNC interface
|
|
System function
|
LCD/keyboard operating, net manager (SNMP)
|
|
Miscellaneous
|
|
Dimension (W× L× H)
|
440mm×410mm×44.5mm
|
|
Approx weight
|
4kg
|
|
Temperature
|
0~45℃(work), -20~80℃(Storage)
|
|
Power
|
AC 100V-220V±10%, 50/60Hz
|
|
Consumption
|
25W
|
