24 Port Dvb-t Saw Filter Sencore Catv Encoder Modulator 64kb/s~384kb/s Each Channel RF CBR/VBR 24-bit CN;SHN 48khz YATAI IBBP
Short Description:
Input | 8HD inputs |
Video | |
Resolution | 1920×1080_60p 1920×1080_50p |
Encoding | MPEG4 AVC/H.264 High Profile Level 4.0 for HD |
Bit-rate | 0.8Mbps~19ps (each channel) |
Rate Control | CBR/VBR |
GOP Structure | IBBP |
Advanced Pretreatment | De-interlacing, noise reduction, sharpening |
Audio | |
Encoding | MPEG-1 Layer 2, HE-AAC,LC-AAC |
Sampling rate | 48KHz |
Resolution | 24-bit |
Bit-rate | 64Kb/s~384Kb/s each channel |
Multiplexing | Multiplex 1ASI input and 8 channels hd encoding programs |
Stream output | 2×ASI outputs, BNC interface(support PID filter and pass, support real time monitoring of the output stream. |
System function | LCD/keyboard operating, network management(SNMP), English control interface |
General | |
Dimensions (W×D×H) | 482mm×455mm×44.5mm |
Approx weight | 3.2 |
Temperature range | 0~45℃(Operating), -20~80℃(Storage) |
Power Requirements | AC 110V±10%, 50/60Hz or AC 220V±10%, 50/60Hz |
Power consumption | 25W |
