Video
|
Video compression: H.264/AVC High Profile Level 4.0
Video inputs: HD-MI(support HDCP protocol), VGA, CVBS, SDI
Analog video input mode: PAL, NTSC
Resolution: 1920*1080_60P, 1920*1080_60i,1920*1080_50i,
1280*720_60P, 1280*720_50P,
Bit-rate: 0.8 ~ 12Mbps, CBR/VBR
Video pre-processing: De-interlacing, Noise reduction, Sharpen
|
|
Audio
|
Audio compression: AAC, MP3
Sampling rate: Adaptive, output sample rate optional
Sampling accuracy: 24-bit
Bit Rate: 32K,44.1K,48K,64K,96K,128K,160K,192K
Encoding bit rate: 64 ~ 384Kbps
|
|
IP output
|
Transport protocol: TS over IP output, RTP/RTMP/RTSP/HTTP/UDP protocol
|
|
System
|
Protocols: HTTP,UDP,RTSP,RTMP,ONVIF
Configuration Interface: Web operation
Upgraded: Can be via network for software upgraded.
Connector: RJ45, 1000M Ethernet interface.
|
|
Physical and power
|
Voltage: 12V DC
Consumption: 5W
Operating temperature: 0~50°C
Dimensions: 170mm(W)*130mm(D)*33mm(H)(for 3U, mini type will be more small )
Weight: 0.5Kg/pc
|
