| item |
| spec |
observation |
| External dimensions (mm) |
| 319.3*214*133(A*B*C) |
319.3*214*133(A*B*C) |
| installation (mm) |
| 52*166*166(DxExF) |
|
| COLOR |
| white/black |
|
| Size and number of holes for optical cable |
| 1 oval optical cable entry, 2 branch optical cable entries 16 pre-attached adapters |
|
| Fusion Capacity (Max) |
| 48 |
Tray A, 12x4=48, 2 layers of shrinkable splice protector handle. |
|
| 64 |
Tray B, 8x8=64, 1 layer of heat shrinkable splice protector handle |
|
| 96 |
Tray C, 8x12=96, 1 layer of heat shrinkable splice protector handle |
|
| 96 |
Tray D and Tray E, 24x4=96, 2 layers of heat-shrink splice protector. |
| micro PLC splitter |
| 1x2 |
Splitter size 60x7x4mm. Can be installed in type A and type E splice tray, 1 piece per splice tray |
|
| 1x4 |
|
|
| 1x8 |
|
|
| 1x16 |
Splitter size 60x7x4mm. Can be installed in type A-1 and type E-1 splice tray, 1 piece per splice tray |
| Largest cable diameter(mm) |
| 8-14mm |
|
| Maximum branch hole size (mm |
| 16mm |
|
| IP protection level |
| IP65 |
|
| Inflammability |
| HB(conventinal) |
|
| Neutral salt spray test(NSS) |
| 48H |
according to the requirements |
