96 Core LC APC Single Mode simplex G652D Step patch cable jumper Fiber Optic Patch Cord
Short Description:
| Construction | |
| Fiber Count（1） | 96fibers |
| Fiber Mode | Single mode: G.652D 9/125µm |
| Connector Type End A | LC/APC simplex 2.0mm connector |
| Connector Type End B | LC/APC simplex 2.0mm connector |
| Connector Ferrule | Zirconia Ceramic |
| Polarity（2） | Type B, |
| Cable Jacket ratings | LSZH |
| Cable Type | Multi core micro cable |
| Cable Diameter | 22.5mm |
| Cable Jackets color | Yellow |
| Cable printing | OPTICAL CABLE FIBER SM G652D 9/125 96core LSZH 10/2022 ****M |
| Connectors color | OS2: Green housing,whie boot |
| Fabout tube diameter | 2.0mm |
| Fabout tube Length End A | 1M |
| Fabout tube Length End B | 1M |
| Temperature | -20°C to +70°C |
