Save Duct Space Single Mode Multimode Micro Air Blown Fiber blowing cable
Short Description:
| PARAMETER | |
| Property / Pass criteria | |
| Fiber Count | |
| 4 to 72 | 144 |
| Number of elements | |
| 6 | 6 |
| Number of fibers per tube | |
| 12 | 24 |
| Cable diameter (nominal) | |
| 5.5 mm | 6.3 mm |
| Cable weight (nominal) | |
| 28 kg/km | 37 kg/km |
| Maximum installation load | |
| 600 N | |
| Minimum bend radius | |
| 12 x OD (Short term) 20 x OD (Long term) | |
| Impact resistance | |
| 1 J | |
| Temperature Cycle | |
| -10 to +70°C | |
| Water penetration (3m cable, 1m head of water) | |
| No leakage |
