| NO |
|
| Item |
|
|
|
| Specifications |
|
|
|
|
|
|
|
| G.657A1 |
|
| 1 |
|
| Cladding Diameter (μm) |
|
|
|
| 125±0.7 |
|
| 2 |
|
| Cladding non-circularity (%) |
|
|
|
| ≤0.7 |
|
| 3 |
|
| Core-cladding concentricity error (μm) |
|
|
|
| ≤0.5 |
|
| 4 |
|
| Mode field Diameter @1310 (μm) |
|
|
|
| (8.6~9.5)±0.4 |
|
| 5 |
|
| Cladding -coating concentricity error (μm) |
|
|
|
| ≤12.0 |
|
| 6 |
|
| Coating Diameter(μm) |
|
|
|
| 245±0.5 |
|
| 7 |
|
| Fiber Cutoff Wavelength (nm) |
|
|
|
| λccf ≤1260 |
|
| 8 |
|
| Attenuation(max.) (dB/km) |
|
| 1310nm |
|
| ≤0.4 |
|
|
|
|
|
| 1550nm |
|
| ≤0.3 |
|
| 9 |
|
| Bend Loss (dB) |
|
| Bend Radius |
|
| 10 |
15 |
|
|
|
|
| Bend Turns |
|
| 1 |
10 |
|
|
|
|
| 1550nm |
|
| ≤0.75 |
≤0.25 |
|
|
|
|
| 1625nm |
|
| ≤1.5 |
≤1.0 |
