Processor
|
Dual-core, 1 GHz
|
|
Memory
|
1 GB
|
|
Flash
|
512 MB
|
|
Micro SD card (default: sd1)
|
None
|
|
Hard disk
|
Not supported
|
|
Dimensions (W x D x H)
|
With no mounting bracket installed: 390.0 mm x 232.5 mm x 44.5 mm (15.35 in. x 9.2 in. x 1.75 in.), 1 U height
With mounting brackets installed: 482.6 mm x 232.5 mm x 44.5 mm (19.0 in. x 9.2 in. x 1.75 in.), 1 U height
|
|
Weight
|
2.9 kg (6.39 lb)
|
|
Rated input voltage range (AC)
|
100 V to 240 V, 50 Hz/60 Hz
|
|
Maximum input voltage range (AC)
|
90 V to 264 V, 47 Hz to 63 Hz
|
|
Maximum input current
|
2 A
|
|
Maximum output power
|
60 W
|
|
RPS power supply
|
Not supported
|
|
PoE power supply
|
Not supported
|
|
Typical power consumption
|
18 W
|
|
Maximum power consumption
|
20 W
|
|
Fans
|
Built-in fans, not pluggable
|
|
Airflow (facing the front panel)
|
Left to right
|
|
Management interfaces
|
1 (RJ45)
|
|
CON/AUX interfaces
|
1 (RJ45)
|
|
USB 2.0 interfaces
|
2
|
|
Service interfaces (standard configuration)
|
WAN interfaces: two GE combo interfaces
LAN interfaces: eight GE electrical interfaces
|
|
Extended slots
|
2xSIC
|
|
Operating temperature
|
0°C to 45°C (32°F to 113°F)
NOTE:
When the altitude is between 1800 m and 5000 m, the highest operating temperature reduces by 1°C every time the altitude increases by 220 m.
|
|
Storage temperature
|
-40°C to +70°C (-40°F to +158°F)
|
|
Operating relative humidity
|
5% to 95%, noncondensing
|
|
Operating altitude
|
< 5000 m (16404.2 ft.)
|
|
Part number
|
02350DQJ
|
