Type |
Unmanaged Switch |
Mode |
S1700-24GR |
Downlink port |
24 Ethernet 10/100/1000 ports |
Uplink port |
Shared with downlink ports |
MAC address table |
8 K MAC |
Dimensions mm (W*D *H) |
442*220*43.6 |
Input voltage |
Rated AC power: 100-240V AC; 50/60Hz
Max AC voltage: 90-264V AC; 47/63Hz
|
EEE |
NA |
Power consumption |
<14.2W |
Operating temperature |
0-1800 m: 0-45℃ 1800-4000 m: decrease 1℃ when the altitude increases every 220 m |
Humidity (noncondensing) |
5%~95% |
Heat dissipation |
Fan-free natural heat dissipation |
