| Part Number |
AIR-AP1852E-H-K9 |
| Description |
802.11ac Wave 2 Access Point, 4x4:4, External-Ant, H Regulatory Domain |
| Features |
- 4x4 MIMO with four spatial streams, single-user MIMO |
|
- 4x4 MIMO with three spatial streams, multiuser MIMO |
|
- MRC |
|
- 802.11ac beamforming (transmit beamforming) |
|
- 20-, 40-, and 80-MHz channels |
|
- PHY data rates up to 1.7 Gbps (80 MHz in 5 GHz) |
|
- Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) |
|
- 802.11 DFS |
|
- CSD support |
| Regulatory Domain |
H (H regulatory domain): |
|
- 2.412 to 2.472 GHz; 3 channels |
|
- 5.150 to 5.350 GHz; 8 channels |
|
- 5.745 to 5.825 GHz; 5 channels |
| Antenna |
External Antenna |
| Interfaces |
- 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) |
|
- 1 x 10/100/1000BASE-T autosensing (RJ-45), AUX (used for Link Aggregation) |
|
- Management console port (RJ-45) |
|
- USB 2.0 (enabled via future software) |
| Dimensions (W x L x H) |
8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
| Weight |
3.12 lb (1.41 kg) |
