Huawei 48 ports Switch S2700-52P-EI-AC S2700 SFP Optical Fiber Switch
Short Description:
| Item | |
| S2700-EI* | S2700-SI/S2710-SI** |
| 100M port | S2700-9TP-SI**/S2700-9TP-EI/S2700-9TP-PWR-EI: 8*10/100Base-TXS2700-18TP-SI/S2700-18TP-EI: 16*10/100Base-TXS2700-26TP-SI/S2700-26TP-EI/S2700-26TP-PWR-EI: 24*10/100Base-TXS2710-52P-SI/S2700-52P-EI/S2710-52P-PWR-SI/S2700-52P-PWR-EI: 48*10/100Base-TX |
| 1000M port | S2700-9TP-SI/S2700-9TP-EI/S2700-9TP-PWR-EI: 1*GE ComboS2710-52P-SI/S2700-52P-EI/S2710-52P-PWR-SI/S2700-52P-PWR-EI:2*100/1000Base-X,2*1000Base-XOthers: 2*GE Combo |
| MAC address table | 8K MAC address entriesManual creation and deletion of MAC address entriesAging time of MAC address entriesDisabling MAC address learning on an interface or aggregation groupLimit on the number of MAC addresses learned on an interfaceBlackhole MAC address entries |
| VLAN | 4K VLANs, complying with IEEE 802.1QPort-based VLAN assignment |
| MAC address-based VLAN assignmentPort-based QinQ assignment | N/A |
| QoS | Port-based rate limiting and flow-based rate limitingFour or eight queues of different priorities on each portMapping between 802.1p priorities and queuesSP, WRR, and SP+WRR algorithms |
| Traffic classification based on the source MAC address, destination MAC address, source IP address, destination IP address, Layer 4 port number, protocol type, VLAN ID, Ethernet protocol, and CoSFlow-based priority marking and packet redirection | N/A |
| IPv6 features | |
| IPv6 hostStatic IPv6 routesIPv6 ACLsMLD v1/v2 snooping | IPv6 hostStatic IPv6 routes |
| Multicast | IGMP v1/v2/v3 snoopingMulticast load balancing among member ports of a trunkPort-based rate limiting and traffic statistics for multicast packets |
| Port mirroring | 1:1 and N:1 port mirroring |
| Traffic mirroring | N/A |
| Security | |
| 802.1x authentication and limit on the number of users on an interfaceDynamic ARP detectionIP source guard | N/A |
| AAA authentication, RADIUS authentication, HWTACACS authentication, and NACBinding of the IP address, MAC address, interface, and VLANPort-based rate limiting Port isolation, port security, and sticky MACPacket filteringPacket filtering based on MAC addressesSuppression of multicast, broadcast, and unknown unicast packetsLimit on the number of learned MAC addressesCPU defense | Port isolationSuppression of multicast, broadcast, and unknown unicast packetsCPU defense |
| Surge protection | 6KV surge protection capability on service ports (1KV on service ports on PoE devices) |
| Device management | StackingAuto-ConfigCLI-based configurationRemote configuration using TelnetSNMP V1/V2/V3RMON HGMP v2SSHv2Web-based device managementGVRP |
| Operating environment | Operating temperature: 0~50C(long term); -5C~5C(short term)Relative humidity: 10%~90% (non-condensing) |
| Power supply | AC: Rated voltage range: 100 V to 240 V AC, 50/60 Hz Maximum voltage range: 90 V to 264 V AC, 50/60 Hz |
| DC:Rated voltage range: -48 V to -60 V DCMaximum voltage range: -36 V to -72 V DCNote: PoE-support switches do not use DC power supplies. | N/A |
| Dimensions (W x D x H) | S2700-9TP-EI/SI: 250 mm x 180 mm x 43.6 mmS2700-9TP-PWR-EI: 320 mm x 220 mm x 43.6 mmS2700-18TP-EI/SI, S2700-26TP-EI/SI, S2710-52P-SI/S2700-52P-EI: 442 mm x 220 mm x 43.6 mmS2700-26TP-PWR-EI/S2710-52P-PWR-SI/S2700-52P-PWR-EI:442 mm x 420 mm x 43.6 mm |
| Weight | |
| S2700-9TP-EI < 1.4 kgS2700-9TP-PWR-EI < 2.5 kgS2700-18TP-EI < 2.4 kgS2700-26TP-EI < 2.4 kgS2700-52P-EI < 3kgS2700-26TP-PWR-EI < 4 kg(without power supply)S2700-52P-PWR-EI < 4.3 kg(without power supply) | S2700-9TP-SI < 1.4 kgS2700-18TP-SI < 2.4 kgS2700-26TP-SI < 2.4 kgS2710-52P-SI < 3 kgS2710-52P-PWR-SI < 4.3 kg(without power supply) |
| Power consumption | |
| S2700-9TP-EI < 12.8 WS2700-18TP-EI < 14.5 WS2700-26TP-EI<15.5 WS2700-52P-EI < 38 WS2700-9TP-PWR-EI < 154 W (PoE: 124 W)S2700-26TP-PWR-EI < 808W (PoE: 740 W)S2700-52P-PWR-EI < 880W (PoE: 740 W) | S2700-9TP-SI < 12.8 WS2700-18TP-SI < 14.5 WS2700-26TP-SI < 15.5 WS2710-52P-SI < 38 WS2710-52P-PWR-SI < 880 W(PoE: 740 W) |
