| Dimensions without packaging (H x W x D) [mm(in.)] |
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
|
| Dimensions with packaging (H x W x D) [mm(in.)] |
90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) |
| Chassis height [U] |
1 U |
| Weight without packaging [kg(lb)] |
3.69 kg (8.14 lb) |
| Weight with packaging [kg(lb)] |
4.45 kg (9.81 lb) |
| Typical power consumption [W] |
30.8 W |
| Typical heat dissipation [BTU/hour] |
105.09 BTU/hour |
| Maximum power consumption [W] |
34 W |
| Maximum heat dissipation [BTU/hour] |
116.01 BTU/hour |
| MTBF [year] |
62.05 year |
| MTTR [hour] |
2 hour |
| Availability |
>0.99999 |
| Noise at normal temperature (acoustic power) [dB(A)] |
Noise-free (no fans), < 30 |
| Noise at normal temperature (acoustic pressure) [dB(A)] |
Noise-free (no fans), < 20 |
| Number of card slots |
0 |
| Number of power slots |
0 |
| Number of fans modules |
0 |
| Redundant power supply |
Not supported |
| Long-term operating temperature [°C(°F)] |
–5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.51 ft.) |
| Short-term operating temperature [°C(°F)] |
Not supported |
| Restriction on the operating temperature variation rate [°C(°F)] |
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Devices cannot start when the temperature is lower than 0°C (32°F).
When the following optical modules are used, the device can operate in the temperature range of –5°C to +40°C (23°F to 104°F):
10GE non-industrial optical module with a transmission distance of 10 km
Non-industrial FE/GE optical module with a transmission distance of 40 km or 80 km
|
| Storage temperature [°C(°F)] |
-40°C to +70°C (-40°F to +158°F) |
| Long-term operating relative humidity [RH] |
5% to 95%, noncondensing |
| Long-term operating altitude [m(ft.)] |
0-5000 m (0-16404 ft.) |
| Storage altitude [m(ft.)] |
0-5000 m (0-16404 ft.) |
| Power supply mode |
AC built-in |
| Rated input voltage [V] |
AC input: 100 V AC to 240 V AC, 50/60 Hz |
| Input voltage range [V] |
AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz |
| Maximum input current [A] |
2 A |
| Memory |
512 MB |
| Flash memory |
512 MB |
| Console port |
RJ45 |
| Eth Management port |
Not supported |
| USB |
Supported |
| RTC |
Not supported |
| RPS input |
Not supported |
| Service port surge protection [kV] |
Common mode: ±7 kV |
| Power supply surge protection [kV] |
±6 kV in differential mode, ±6 kV in common mode |
| Types of fans |
None |
| Heat dissipation mode |
Natural heat dissipation |
| Airflow direction |
- |
| PoE |
Not supported |
| Certification |
EMC certification
Safety certification
Manufacturing certification
|
