Processor
|
Six-core, 1.2 GHz
|
|
Memory
|
2 GB
|
|
Flash
|
32 MB
|
|
Micro SD card (default sd1)
|
2 GB
|
|
Hard disk
|
Not supported
|
|
Dimensions (W x D x H)
|
With no mounting bracket installed: 442.0 mm x 470.0 mm x 88.1 mm (17.4 in. x 18.5 in. x 3.47 in.), 2 U height
With mounting brackets installed: 482.6 mm x 470.0 mm x 88.1 mm (19.0 in. x 18.5 in. x 3.47 in.), 2 U height
|
|
Weight
|
8.85 kg
|
|
AC model (using 350 W AC power modules)
|
Supports two hot swappable 350 W AC power modules.
|
|
Rated input voltage range (AC)
|
100 V to 240 V, 50 Hz/60 Hz
|
|
Maximum input voltage range (AC)
|
90 V to 264 V, 47 Hz to 63 Hz
|
|
Maximum input current
|
5 A
|
|
RPS power supply
|
Not supported
|
|
PoE power supply
|
Not supported
|
|
AC PoE model (using 850 W PoE AC power modules)
|
Supports two hot swappable 850 W PoE AC power modules.
|
|
Rated input voltage range (AC)
|
100 V to 240 V, 50 Hz/60 Hz
|
|
Maximum input voltage range (AC)
|
90 V to 264 V, 47 Hz to 63 Hz
|
|
Maximum input current
|
10 A
|
|
Maximum output power
|
850 W
|
|
RPS power supply
|
Not supported
|
|
PoE power supply
|
Supported
|
