Memory (RAM)
|
512 MB
|
Flash
|
512 MB in total. To view the available flash memory size, run the display version command.
|
Dimensions (W x D x H)
|
442.0 mm x 310.0 mm x 43.6 mm (17.4 in. x 12.2 in. x 1.72 in.)
|
Weight (including packaging materials)
|
5.2 kg (11.45 lb)
|
Stack ports
|
Twenty-four 10/100/1000BASE-T ports and four 1000BASE-X ports
|
RTC
|
Not supported
|
RPS
|
Supported
|
PoE
|
Supported
|
Rated voltage range
|
100 V AC to 240 V AC, 50/60 Hz
|
Maximum voltage range
|
90 V AC to 264 V AC, 47 Hz to 63 Hz
|
Maximum power consumption (100% throughput, full speed of fans)
|
Not providing the PoE function: 42.7 W
100% PoE loads: 448.5 W (system power consumption: 78.9 W, PoE: 369.6 W)
|
