huaweie 2 ports 10GE/GE OLT Uplink Interface Board H803X2CK H801X2CK X2CK for MA5600T Series OLT
Short Description:
| Item | Specifications |
| Number of 10G GPON ports supported by each board | 4 |
| Port mode | XFP |
| Optical module | One-fiber bi-directional optical module. |
| Number of GEM Port supported by each port | 4096 |
| Number of T-CONT supported by each port | 2048 |
| Split ratio | Supports a maximum of 1:128 split ratio. The actual split ratio is determined according to the model of optical modules and thedistance of optical fibers. |
| Optical module management | Support the function for querying 10G GPON optical module parameters, such as temperature, bias current, voltage, and receiveoptical power. |
| Board management | Received signal strength indicator (RSSI) detection and controlled optical signal transmission of the optical moduleONU-based shapingTemperature query and board power-off in case of a high temperature |
