HIOSO CP582N is a high-performance, high-speed 4G wireless router that can provide 2.4GHz wireless speeds up to 300Mbps.
Short Description:
| Hardware specifications | |
| Product number | |
| HIOSO CP582N | |
| CPU | |
| MT7628DAN | |
| Flash | |
| SPI NOR 8MB | |
| DDR | |
| Built-in 64MB | |
| 2.4G working frequency band | |
| 2.4GHz ~ 2.484GHz | |
| 2.4G WIFI transmission protocol | |
| 802.11 b / g / n | |
| WiFi antenna | |
| 2 external 2.4GHz antennas, gain: 3dBi | |
| 4G antenna | |
| 2 external 4G antennas, gain: 3dBi | |
| maximum rate | |
| 2.4GHz provides a maximum access rate of 300Mbps | |
| 2.4GHz wireless power | |
| 802.11b | |
| 11M | |
| 20±2dBm | |
| 1M | 20±2dBm |
| 802.11g | |
| 54M | |
| 18±2dBm | |
| 6M | 19±2dBm |
| 802.11n HT20 | |
| MCS7 | |
| 18±2dBm | |
| MCS0 | 19±2dBm |
| 802.11n HT40 | |
| MCS7 | |
| 17±2dBm | |
| MCS0 | 19±2dBm |
| 2.4GHz receiving sensitivity | |
| 802.11b | |
| 11M | |
| -87dBm | |
| 1M | -94dBm |
| 802.11g | |
| 54M | |
| -75dBm | |
| 6M | -88dBm |
| 802.11n HT20 | |
| MCS7 | |
| -72dBm | |
| MCS0 | -88dBm |
| 802.11n HT40 | |
| MCS7 | |
| -65dBm | |
| MCS0 | -88dBm |
| 2.4G EVM | |
| 802.11b: ≤-10 dB ；802.11g: ≤-25 dB ；802.11n: ≤-28 dB | |
| Frequency deviation (ppm) | |
| ±20ppm | |
| Interface (WAN) | |
| 1 10/100M adaptive WAN port | |
| Interface (LAN) | |
| 2 10/100M adaptive LAN ports | |
| interface | |
| SIM card socket | |
| 4G module | |
| EC200A-CNLA | |
| external keys | |
| reset button (press and hold for 6-10 seconds to restore factory default configuration) | |
| Status Indicator | |
| System light, WAN port light, LAN port light | |
| powered by | |
| DC 12V/1A | |
| Maximum power consumption | |
| < 6W | |
| Product Size/weight | |
| 200mm×125mm×190mm，0.35kg | |
| working environment | |
| Normal operating temperature: -5°C to 45°C; Storage temperature: -40°C to 70°C; Humidity: 5% to 95% (no condensation) | |
| ESD | |
| Air discharge +/-8K, contact discharge +/-4K | |
| surge | |
| Common mode 2K, differential mode 1K | |
