Parameter |
Specification |
Operating wavelength |
1310 (RX)/1490(TX) |
Optical power |
+2 ~ +7dBm |
Receiving sensitivity |
-27dBm |
Max distance |
60km |
Max splitter ratio |
1:256 |
Capacity |
8 PON, 256 ONUs |
Upstream ports |
10 GE optical and GE optical/electrical ports |
PON port |
8 SC fiber port |
Control port |
RJ45, RS232, to debug the device |
MTBF |
about100,000 hours |
Access Capacity |
64 x 10G GPON, 256 x GPON ,768 x GE/FE |
Dimensions (H x W x D) |
447 mm x 490 mm x 275.8 mm |
Operating Environment |
-25°C -55°C |
Relative Humidity (RH) |
5%-95% |
Operating voltage |
-38.4V-72V |
