| Port Type |
| Port |
Description |
| Upstream port |
| GE optical/electrical port |
use the Single-mode / multi-mode SFP optical transceivers.
supports different transmission by different SFP.
Multi-GE upstream transmission is supported to meet the multi-edge network requirements of the carrier.
|
| 10GE optical port |
the 10GE upstream transmission |
| E1 port |
the E1 upstream transmission |
| STM-1 port |
the upstream transmission through the
STM-1 optical port. supports ESFP/SFP module
|
| Service port |
| GPON port |
the GPON access.
Maximum upstream rate: 1.244 Gbit/s
Maximum downstream rate: 2.488 Gbit/s
|
| P2P optical port |
P2P Ethernet optical access, 100 Mbit/s. |
| Ethernet optical port |
GE subtending |
| Maintenance port |
| Maintenance serial port |
for local and remote maintenance |
| Environment monitoring serial port |
the monitoring device collects various environment parameters. this port reports to the MA5680T. |
