Technical Item
|
Details
|
|
PON interface
|
1 G/EPON port(EPON PX20+ and GPON Class B+)
Upstream: 1310nm; Downstream: 1490nm
SC/APC connector
Receiving sensitivity: ≤-27dBm
Transmitting optical power: 0~+4dBm
Transmission distance: 20KM
|
|
LAN interface
|
1x10/100/1000Mbps and 1x10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
|
|
WIFI Interface
|
Compliant with IEEE802.11b/g/n
Operating frequency: 2.400-2.4835GHz
support MIMO, rate up to 300Mbps
2T2R,2 external antenna 5dBi
Support: Multiple SSID
Channel:13
Modulation type: DSSS,CCK and OFDM
Encoding scheme: BPSK,QPSK,16QAM and 64QAM
|
|
CATV Interface
|
RF, optical power : +2~-18dBm
Optical reflection loss: ≥45dB
Optical receiving wavelength: 1550±10nm
RF frequency range: 47~1000MHz, RF output impedance: 75Ω
RF output level: ≥ 82dBuV(-7dBm optical input)
AGC range: +2~-7dBm/-4~-13dBm/-5~-14dBm
MER: ≥32dB(-14dBm optical input), >35(-10dBm)
|
|
POTS Port
|
RJ11
Max 1km distance
Balanced Ring, 50V RMS
|
|
LED
|
10 LED, For Status of WIFI,WPS,PWR,LOS,PON,LAN1~LAN2, WORN,NORMAL(CATV), FXS
|
|
Push-Button
|
4, for Function of Power on/off, Reset, WPS, WIFI
|
|
Operating condition
|
Temperature : 0℃~+50℃
Humidity :10%~90%(non-condensing)
|
|
Storing Condition
|
Temperature : -40℃~+60℃
Humidity :10%~90%(non-condensing)
|
|
Power supply
|
DC 12V/1A
|
|
Power Consumption
|
<6W
|
|
Net Weight
|
<0.4kg
|
