Dimensions (H×W×D)
|
43.6mm×442mm×220mm
|
|
Network-side port
|
Each of them provides two uplink ports that use the SFP optical modules and automatically adapt to GPON and GE modes. The two uplink ports can be configured as follows:
•2×GPON
•2×GE (optical)
•1×GE (optical) + 1×GPON
|
|
User-side port
|
•24×FE + 24×POTS
•16×FE + 16×POTS
•8×FE + 8×POTS
|
|
Operating temperature
|
-40oC to 55oC; startup at -25oC
|
|
Humidity
|
5% to 95% (non-condensing)
|
|
Heat dissipation mode
|
No fans; passive cooling
|
|
Power supply
|
AC: 220V/110V
|
|
Lightning protection capability
|
LAN: 6kV;
POTS: 4kV
|
|
Weight
|
24 ports: 2.3kg
16 ports: 2.29kg
8 ports: 2.28kg
|
