| Technical Specification |
|
| Parameter |
Specifications |
| Operating wavelength |
1310（RX）/1490（TX） |
| Optical power |
+0 ~ +7dBm |
| Receiving sensitivity |
-27dBm |
| Max distance |
20km |
| Max splitter ratio |
1:64 |
| Capacity |
2 PON, standard: 64 maximum:128 ONUs (optional 1:128) |
| MAC |
8K |
| Uplink port |
2 1000M Ethernet RJ45 ports |
| PON port |
2 SFP PON PORTS 1.25G |
| Control port |
RJ45 console port, to debug the device |
| MTBF |
100,000 hours |
| EPON traits |
Support IEEE802.3ah |
|
Support DBA with minimum1Kbps granularity adjustable |
|
Support 1Gbps up link and down link symmetrical bandwidth |
|
Support AES-128 encryption to each Logical Link Identifier |
|
Support powerful OAM function, implement telnet management, maintenance and upgrade |
|
Support auto discovery and auto register of ONU (real-time operation) |
| Protocols supported |
Support IEEE802.3, IEEE802.3u, IEEE802.3ab |
|
Support IEEE802.1Q VLAN |
|
Support IEEE 802.1P QoS |
| Management |
Support 1GMPv1/v2 protocol report, query and leave message mouse |
|
Support ONU remote configure and upgrade |
|
Support real-time alarm detection, accurate fault location |
|
Support the alarm information sent to the mailbox, support SMS alarm |
|
|
| Working Environment |
|
| Power supply |
AC220V |
| Power consumption |
11W |
| Operating temperature |
-10～55℃ |
| Storage temperature |
-40～70℃ |
| Humidity |
5%～90% non-condensing |
| Dimension |
276mm(length) ×200mm(width) ×44mm(height) |
