| Input |
8/12/24CVBS inputs , RCA interface |
| Video |
| Resolution |
720×480_60i, 544×480_60i, 352×480_60i352×240_60i, 320×240_60i,176×240_60i, 176×120_60i |
| Encoding |
MPEG-2 |
| Bit-rate |
0.5Mbps~8Mbps each channel |
| Rate Control |
CBR/VBR |
| GOP Structure |
GOP_0_B, GOP_1_B, GOP_2_B, GOP_3_B |
| Advanced Pretreatment |
De-interlacing, noise reduction |
| Audio |
| Encoding |
MPEG-1 Layer 2, AC3(2.0) |
| Sampling rate |
48KHz |
| Resolution |
24-bit |
| Bit-rate |
64Kbps,128Kbps,192kbps,256kbps,320kbps,384kbps each channel |
| Multiplexing |
| Function |
PID remapping (automatically or manually) |
| Stream output |
1 ASI as copy of MPTSIP (MPTS/SPTS) output over UDP/RTP/RTSP8/12 CVBS inputs with 8/12 SPTS and 1 MPTS output24×CVBS inputs with 24 SPTS or 1 MPTS output |
| System function |
Network management (WEB) |
| Miscellaneous |
| Dimension(W×L×H) |
482mm×410mm×44mm |
| Approx weight |
8kg |
| Environment |
0~45℃(work);-20~80℃(Storage) |
| Power requirements |
AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz |
| Power consumption |
20W |
