Input
|
8HD inputs
|
Video
|
Resolution
|
1920×1080_60p 1920×1080_50p
|
Encoding
|
MPEG4 AVC/H.264 High Profile Level 4.0 for HD
|
Bit-rate
|
0.8Mbps~19ps (each channel)
|
Rate Control
|
CBR/VBR
|
GOP Structure
|
IBBP
|
Advanced Pretreatment
|
De-interlacing, noise reduction, sharpening
|
Audio
|
Encoding
|
MPEG-1 Layer 2, HE-AAC,LC-AAC
|
Sampling rate
|
48KHz
|
Resolution
|
24-bit
|
Bit-rate
|
64Kb/s~384Kb/s each channel
|
Multiplexing
|
Multiplex 1ASI input and 8 channels hd encoding programs
|
Stream output
|
2×ASI outputs, BNC interface(support PID filter and pass, support real time monitoring of the output stream.
|
System function
|
LCD/keyboard operating, network management(SNMP), English control interface
|
General
|
Dimensions
(W×D×H)
|
482mm×455mm×44.5mm
|
Approx weight
|
3.2
|
Temperature range
|
0~45℃(Operating), -20~80℃(Storage)
|
Power Requirements
|
AC 110V±10%, 50/60Hz or AC 220V±10%, 50/60Hz
|
Power consumption
|
25W
|
