Item
|
|
Description
|
Remark
|
|
Input Optical Power Range
|
|
-15~+2dBm
|
|
|
AGC:-12~-2 dBm
|
|
|
Responsivity
|
|
≥0.9A/W
|
|
|
Optical Return Loss
|
|
≥45dB
|
SC/APC
|
|
Receive Wavelength
|
|
1260~1600nm
|
|
|
Frequency Range
|
|
45-2400MHz
|
CATV &SAT-IF
|
|
CATV
|
|
Flatness
|
|
±1.0dB(47~1000MHz)
|
|
|
Output Level
|
|
≥78dBμV
|
-12~-2 dBm/AGC
|
|
CNR/CSO/CTB
|
|
≥50dB/≥60dB/≥65dB
|
-1dBm input power
|
|
MER/BER
|
|
≥32(64QAM)/≤1×10-4
|
-12dBm
|
|
Return Loss
|
|
≥14dB(47~1000MHZ)
|
Output Impedance/75Ω
|
|
AGC Stability
|
|
±1dB(-12~-2 dBm)
|
|
|
SAT-IF
|
|
Flatness
|
|
±1.5dB(1000~2400MHz)
|
It varies with the input level.
|
|
Output Level
|
|
78 dBuv
|
-12~-2 dBm/AGC
|
|
Return Loss
|
|
≥10dB(1000~2150MHz)
|
Output Impedance/75Ω
|
|
AGC Stability
|
|
±1dB(-12~-2 dBm)
|
|
|
RF Connector
|
|
Inch (two way output)
|
|
|
Optical Connector
|
|
SC/APC
|
|
|
Power Supply
|
|
5V/500mA
|
outlay AC90~255V→DC5V
|
|
Power Consumption
|
<2W
|
|
Working / storage temperature
|
|
-5~45℃/-25~75℃
|
5~90(Non-condensation)
|
|
Dimensions
|
|
92×80×25mm
|
Iron box structure
|
