FCTEL 1-4channels dry contact closure optic fiber converter
Short Description:
| Optic fiber | |
| wavelength | 850nm/1310nm MM; 1310nm/1550nm SM |
| typical transmitting power | SM1310/1550nm:≥-9dBm |
| MM850nm:-18dBm | |
| MM1310nm:-25dBm | |
| sensitivity range | -28dBm~- 40dBm |
| Dry contact closure(dry contact) | |
| interface type | signal relay interace |
| respond time | <1.2ms |
| signal output | 30VDC/0.5A |
| frequency | 50Hz |
| Dry contact closure(wet contact) | |
| interface type | optic MOS relay interface |
| respond time | <0.5ms |
| signal output | 30VDC/0.5A |
| Frequency | 50Hz |
| output surge protection | TVS + TSS protection |
