| Mode |
| SM |
MM |
| Polish |
| UPC |
| APC |
PC |
| Insertion Loss |
|
Typical ≤0.2dB
Maximum ≤0.3dB
|
≤0.25dB |
| Return Loss |
|
≥50dB
|
| ≥65dB |
≥35dB |
| Interchangeability |
≤0.2dB |
| Repeatability |
≤0.1dB |
| Durability |
≤0.2dB (500 times mating) |
| Tensile Strengh |
≥50N |
| Temperature |
≤0.2dB (-40+85 sustain 100 hours) |
| Humidity |
≤0.2dB (+25+65 93 R.H.100 hours) |
