Memory (RAM)
|
2 GB
|
|
Flash
|
512 MB in total. To view the available flash memory size, run the display version command.
|
|
Mean time between failures (MTBF)
|
80.60 years when no interface card is configured; 70.79 years when a 4-port 40GE interface card is configured
|
| Mean time to repair (MTTR) |
2 hours
|
|
Availability
|
> 0.99999
|
|
Service port surge protection
|
NA
|
|
Power supply surge protection
|
Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode
Using DC power modules: ±1 kV in differential mode, ±2 kV in common mode
|
|
Dimensions (W x D x H)
|
442.0 mm x 420.0 mm x 44.4 mm (17.4 in. x 16.5 in. x 1.74 in.)
|
|
Weight (including packaging materials)
|
9.8 kg (21.61 lb) |
|
Stack ports
|
Any 10GE SFP+ ports on the front panel (a maximum of 16 physical ports)
Any 40GE QSFP+ ports (a maximum of 6 physical ports)
|
|
RTC
|
Supported
|
|
RPS
|
Not supported
|
|
PoE
|
Not supported
|
|
Rated voltage range
|
100 V AC to 240 V AC, 50/60 Hz
-48 V DC to -60 V DC
|
|
Maximum voltage range
|
90 V AC to 264 V AC, 47 Hz to 63 Hz
-38.4 V DC to -72 V DC
|
