Network Standard |
IEEE 802.3,IEEE 802.3u,IEEE 802.3x |
Port |
3*10/100Mbps RJ45 power supply port
1*10/100Mbps RJ45 receiving port
|
POE Power |
The whole power is 30W
Output power of single port is 24W, average output power per port is 8W
|
POE Connection |
POE input receiving wire core:1/2+,3/6- ,4/5+,7/8-
POE output power supply core:1/2+,3/6-
250m Transmission
|
Performance |
Store and forward
MAC address table 1k
Switching capacity 1.6Gbps
|
Forwarding Rate |
10BASE-T:14880PPS/port
100BASE-tx:148800pps/port
|
Port Function |
Power priority mechanism, fast and forward, MAC automatic
learning and aging IEEE802.3X Full-duplex and backpressure for half-duplex mode
|
Working Environment |
Operating Temperature:-10℃ - -55℃ |
Power |
Input: DC44-57V, 30W; Output: DC44-57V, 24W |
Weight &Size |
118g
140mmx32mmx84mm(L×W×H)
|
