AP2050DN AP2000 Series Access Points
Short Description:
| Specifications | AP2050DN |
| Dimensions (H x W x D) | 140 mm x 86 mm x 36 mm |
| Power Input | DC: 48V ±5% |
| PoE power supply: In compliance with IEEE 802.3af/at | |
| Maximum Power Consumption | 11.5W |
| Note: The actual maximum power consumption depends on local laws and regulations | |
| Operating Temperature | 0°C to 40°C |
| Antenna Type | Built-in antenna |
| Maximum Number of Users | ≤ 256 |
| Maximum Transmit Power | 2.4G: 21 dBm (combined power) |
| 5G: 20 dBm (combined power) | |
| Notes: The actual transmit power depends on local laws and regulations. The AP2050DN uses a 86-type box and applies only to countries and regions that support 86-type boxes | |
| MIMO: Spatial Streams | 2 x 2:2 |
| Radio Protocols | 802.11a/b/g/n/ac/ac wave 2 |
| Maximum Rate | 1.267 Gbit/s |
