Industrial POE Switch 10 Port 100Base-T DIN Rail Wall Mounted Gigabit Uplink SFP Network Ethernet Switcher, DC 48-55V
Short Description:
| Power | DC48-55V |
| Ethernet Port | 8* 10/100M PoE Ports1* Gigabit Uplink port1* Gigabit SFP Port |
| Bandwidth | 5.6Gbps |
| PackageForwarding Rate | 4.166Mpps |
| MAC Address | 8K |
| Jumbo frame | 9.6Kbytes |
| Forwarding mode | Store and forward |
| MTBF | 100000 Hours |
| NetworkProtocols | IEEE802.3IEEE802.3uIEEE802.3z |
| POE protocol | PoE standard: IEEE802.3af /IEEE802.3at Single port max: 15.4 W (IEEE 802.3af)Single port max: 30 W (IEEE 802.3at) PoE compatibility: IEEE 802.3af/at self-adaptive PoE port output voltage: DC 48-55VPoE power supply wire core:1/2+ ; 3/6- |
| Network Media | 10BASE-T: Cat5 or more UTP(≤100 m)100BASE-TX: Cat5 or more UTP(≤100 m)1000BASE-TX: Cat5 or more UTP(≤100 m) |
| Fiber Media | Multi-mode fiber: 850nm, 1310nm transmission distance: 550m/2KmSingle-mode fiber: 1310nm, 1550nm transmission distance:20/40/60/80/100/120km |
| Safety Certificate | CE ,FCC,ROHS |
| WorkingEnvironment | Operating Temperature: -40~75℃Storage Temperature: -40~85℃Humidity: 5%~95 %( non-condensing) |
| LED indicator | PWR, 1-8 Green, G10 |
| PWR | Lighting:PoweredUn-Light:No Power |
| 1-8 Green | Slow flashing: 10/100M link normalOff: Link offFast flashing: Link data transmitting |
| G10 | On: Optical connecting properlyOff: Optical offFlashing: Optical data transmitting |
| DIP function | V,G,E(open up, close down) |
| V | V: VLAN mode, ports 1-8 are isolated and can communicate withport 9 and 10 |
| G | G: Normal mode |
| E | E: Extend mode, ports 1-8 are reduced to 10M and can be extendedto 250m |
| Specification Size | Product dimension: 138*108*44 mmPackage dimension: 245*190*60mmProduct N.W: 0.646 KGProduct G.W: 0.781 KG (without power) |
| Voltage | Voltage input: DC48~55VPower cable :4 PIN Industrial terminal (redundancy V1+V1-,V2+V2-)/ DC 2.1 (DC 2.1 cannot be used together with V1 and V2) |
| Packing List | 1. Industrial Switch: 1 PC2. User Manual: 1 PC3. Certification: 1 PC4. Pull-arm: 1 PC |
