Original Cis co 9115AX Series WiFi 6 access point long range C9120AXI-i,c9120axi-b
Short Description:
| Product Name | |
| c9120AXI-I | |
| Software | |
| ● Cisco Unified Wireless Network Software Release 8.9 or later● Cisco IOS XE Software Release 16.11 or later | |
| Software and supported wireless LAN controllers | |
| ● Cisco Catalyst 9800 Series Wireless Controllers● Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller | |
| 802.11n version 2.0 (and related) capabilities | |
| ● 4x4 MIMO with four spatial streams● Maximal Ratio Combining (MRC)● 802.11n and 802.11a/g beamforming● 20- and 40-MHz channels● PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)● 802.11 Dynamic Frequency Selection (DFS)● Cyclic Shift Diversity (CSD) support | |
| 802.11ac | |
| ● 4x4 downlink MU-MIMO with four spatial streams● MRC● 802.11ac beamforming● 20-, 40-, 80-, and 160-MHz channels● PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)● 802.11 DFS● CSD support | |
| 802.11ax | |
| ● 4x4 downlink MU-MIMO with four spatial streams● Uplink/downlink OFDMA● TWT● BSS coloring● MRC● 802.11ax beamforming● 20-, 40-, 80-, and 160-MHz channels● PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)● 802.11 DFS● CSD support | |
| Integrated antenna | |
| ● 2.4 GHz, peak gain 3 dBi, internal antenna, omnidirectional in azimuth● 5 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth | |
| Input power requirements | |
| ● 802.3at Power over Ethernet Plus (PoE+), 802.3bt Cisco Universal PoE (Cisco UPOE+, Cisco UPOE)● Cisco power injector, AIR-PWRINJ6=● 802.3af PoE● Cisco power injector, AIR-PWRINJ5= (Note: This injector supports only 802.3af)Note: When 802.3af PoE is the source of power, both 2.4-GHz and 5-GHz radios will be reduced to 2x2 and Ethernet downgraded to 1Gigabit Ethernet. In addition, the USB port will be off. | |
| Dimensions(W x L x H) | |
| ● Access point (without mounting brackets): C9120AXI: 8.5 x 8.5 x 1.7” (21.6 x 21.6 x 4.3 cm), C9120AXE and C9120AXP: 8.5 x 8.05 x2.0” (21.6 x 21.6 x 5.1 cm) | |
| Weight | |
| Cisco Catalyst 9120AXI● 2.87 lb (1.3 kg)Cisco Catalyst 9120AXE/P● 3 lb (1.36 kg) | |
