HW AP2000 Series access point wifi AP2051DN

Short Description:


Product Detail

Specifications AP2051DN and AP2051DN-E
Dimensions (H x W x D) 32.5 mm x 86 mm x 150 mm
Power Input DC: 45.6V to 57VPoE power supply: In compliance with IEEE 802.3af/at
Maximum Power Consumption AP2051DN: 11.5W (excluding the output power of the USB port)AP2051DN-E: 11.5W (excluding the output power of the USB port and PoE_OUT port)Note: The actual maximum power consumption depends on local laws and regulations
Interface types Uplink: 1 x GEDownlink: 4 x GE2 x Pass-through RJ45 port1 x USB port
Built-in Bluetooth BLE4.1 (supported by the AP2051DN-E)
PoE OUT Supported by AP2051DN-E: Maximum 13.6W (802.3at-compliant, 48V DC, supported only by GE4)
Operating Temperature 0°C to 40°C
Antenna Type Built-in smart antennas
Maximum Number of Users ≤ 256
Maximum Transmit Power 2.4G: 23 dBm (combined power)5G: 23 dBm (combined power)Note: The actual transmit power depends on local laws and regulations.
MIMO: Spatial Streams 2 x 2:2
Radio Protocols 802.11a/b/g/n/ac/ac wave 2
Maximum Rate 1.267 Gbit/s
