Parameter
|
Specification
|
|
Wavelength
|
1310(TX)/1490(RX)
|
|
Optical power
|
-1~+4dBm
|
|
Receiving sensitivity
|
-25dBm
|
|
Max transmission distance
|
20 km
|
|
Space of buffer storage
|
1.25MB
|
|
MTBF
|
100,000 hours
|
|
PON connector
|
SC/PC
|
|
EPON trait
|
Support IEEE802.3ah
Support Dynamic Bandwidth Allocation (DBA)
Support ONU auto-searching and automatic registration (real-time operation)
|
|
Standard and Protocol
|
Support IEEE802.3, IEEE802.3u
IGMP Snooping V2
Support IEEE802.1q WLAN
Support IEEE802.1p QOS
|
|
POE
|
Supplying power port: 4 ports
Standard: IEEE802.3af 15.4W, IEEE802.3at 30W
Working mode: auto discover and power/dis-power receiving power device
|
|
Network management
|
Cooperating with center OLT, implement management configuration and software upgrade to ONU
|
