Huawei GPON Mini OLT MA5608T
Short Description:
| Standard compliance | ETSI cabinet (21-inch): ETSI 300 119-3 |
| Weight (empty cabinet) | 45 kg |
| Dimensions (W x D x H) | 600 mm x 300 mm x 2200 mm |
| Installation dimensions of the cabinet top | Installation interface Hole positions: 413 mm x 200 mm (W x D) Nut specifications: four M8 nuts |
| Installation dimensions of the cabinet bottom | Installation interface Hole positions: 413 mm x 187 mm (W x D) Bolt specifications: four M12 expansion bolts |
| Distance between mounting bar holes | 1 SU = 25 mm. (SU: System Unit.) |
| Available space | 83 SU |
| Angle opening width | 500 mm |
| Fixing centres | 515 mm |
| Distance between the installation surface of the mounting bar and the inner side of the air filter on the cabinet front door | 47 mm |
