HA7316CX EPON OLT provides 16 EPON ports 12 uplink ports 4 ports 10G uplink single power supply without modules
Short Description:
Items | Specifications |
PON standard | EPON IEEE802.3ah |
PON interface | 16*EPON SFP Ports (PX20+), Receiving sensitivity: ≤-30dBm(Saturation Optical -6dBm). Power,Transmitting optical power: +2~+7dBmTransmissiondistance: 20KM. Max splitting ratio1:64 |
Upstream 1.25G Downstream 1.25G | |
Wavelength | Tx1310nm, Rx 1490nm |
Uplink | 4*copper ethernet ports 10/100/1000M auto-negotiation |
4*SFP(GE) | |
4*SFP+ (10GE) | |
Layer 3 | Support static route、dynamic route RIP v1/v2 and OSPF |
Management Ports | 1*10/100BASE-T out-band port, 1*CONSOLE port |
Management Mode | SNMP、Telnet、CLI 、WEB、SSH v1/v2 |
Backplane | 128Gbps |
MAC table | 16K |
Operating condition | Operating temp: -5℃ ~ +55℃ |
Storing condition | Storing temp: -40℃ ~ +85℃ |
Humidity | 5~90%(non-condensing) |
Power consumption | ≤95W |
Dimension | 442mm×320mm×44mm(L×W×H) |
Net weight | 6.5Kg |
