New design epon Industrial gepon 24 ports poe onu supply fttx solutions olt
Short Description:
| Parameter | Specification |
| Wavelength | 1310(TX)/1490(RX) |
| Optical power | -1~+4dBm |
| Receiving sensitivity | -25dBm |
| Max transmission distance | 20 km |
| Cache space | 1.25MB |
| MTBF | 100,000 hours |
| PON connector | SC/PC |
| EPON trait | Support IEEE802.3ah Support Dynamic Bandwidth Allocation (DBA) Support ONU auto-searching and automatic registration |
| Standard and Protocol | Support IEEE802.3, IEEE802.3u IGMP Snooping V2 Support IEEE802.1q WLAN Support IEEE802.1p QOS |
| POE | Supplying power port: 24 ports Standard: IEEE802.3af 15.4W, IEEE802.3at 30W Working mode: auto discover and power/dis-power receiving power device |
| Network management | Cooperating with center OLT, implement management configuration and software upgrade to ONU |
